    2dB Noise Figure Wireless Mic Antenna System 50/60Hz For Large Scale Performance

    Ask Lasest Price
    Brand Name : GESTTON
    Model Number : TS-1000
    Certification : CE ROHS FCC
    Price : Negotiate
    Payment Terms : T/T, Western Union
    Supply Ability : 10000 pics/month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    2dB Noise Figure Wireless Mic Antenna System 50/60Hz For Large Scale Performance

    Professional Wireless Microphone TS1000 UHF Microphone Antenna System


    TS-1000 4-Channel Antenna Divider


    Features:


    Ultra-wide band 470-1000 MHz .


    Compatible with up to 4 UHF wireless receivers to one set of antenna.


    Adopts the latest wide dynamic range and low noise component.


    Advanced circuit design featuring very low inter-modulation distortion and eliminates the spurious interference.


    BNC antenna connecters.


    Allows daisy-chain antenna dividers for more receivers.


    Main Frame SizeEIA-Standard 19" 1 U
    Frequency RangeUHF 470--1000 MHz
    Output Gain1 dB ± 1 dB
    IIP3+14 dBm
    Noise Figure< 2 dB
    Impedance50Ω
    ConnectorBNC
    Antenna Power Supply12V / 150 mA DC
    Output Power SupplyEach Channel: 12V / 1000 mA DC
    Power Supply110-240V AC 50/60 Hz
    Dimensions (mm)483 (W) x 45 (H) x 213 (D)
    Weight2.25KG

    2dB Noise Figure Wireless Mic Antenna System 50/60Hz For Large Scale Performance


    Application



    Ideally suitable for small scale boardrooms and meeting rooms, Large Meeting Room, Large lecture seminar.


    OUR ADVANTAGES
    We are a powerful factory with a large number of audio products and OEM/ODM services for customers.

    OUR FACTORY
    Welcome to our company ,a one-stop solution for your Microphone business
    Condenser Microphone For Laptop, Desktop Computer,Mobile Phone With Plug And Play effect 6

    Function Discussion Video Professional Wired Microphones Gooseneck Microphone Conference System 13Function Discussion Video Professional Wired Microphones Gooseneck Microphone Conference System 14


    Certification


    Shipment

    It is an ultra-high frequency, broadband and low noise amplifier used between antenna and feeder. Compensate the loss of transmission distance between antenna and TV, and ensure that the distributor obtains the necessary input power in the common antenna system
